Alumapro Alchemy MX 10 10-Inch Metal Cone Subwoofer
Alumapro Alchemy MX 10 10-Inch Metal Cone Subwoofer
The Alchemy MX 10 is Alumapro's sound-quality 10 for sealed boxes. Alumapro's proprietary FEA-designed alloy cone, an aero-vented cast frame, 12 mm of excursion and 300 W RMS deliver deep, accurate bass that keeps pace with a serious front stage.
Highlights
- Proprietary FEA-designed alloy cone
- Heat-dissipating integrated cone assembly
- Proprietary cast frame with aero venting
- Massive vented motor structure
- High-temp aluminum composite voice coil
- Laminated Nomex suspension with high-roll Santoprene rubber surround
- 12 mm Xmax
- Optimized for sealed boxes
- 300 W RMS / 600 W peak
- Available in single 4-ohm, single 8-ohm, dual 4-ohm and dual 6-ohm voice coil
Best for
Sealed boxes of 0.65–0.75 ft³, in daily drivers and sound-quality systems. Also available: the Alchemy MX 10 Free-Air.
Specifications
| Parameter | Single 4 Ohm | Single 8 Ohm | Dual 4 Ohm | Dual 6 Ohm |
|---|---|---|---|---|
| Impedance (Ohms) | 4 | 8 | 4/4 DVC | 6/6 DVC |
| Fs (Hz) | 35 | 36 | 34 | 36 |
| Qms | 6 | 5 | 6 | 5 |
| Qes | .46 | .49 | .53 | .56 |
| Qts | .42 | .44 | .49 | .50 |
| Vas (Ft³) | 1.0 | 1.0 | 1.1 | 1.1 |
| Re (Ohms) | 3.9 | 7.9 | 1.63 (Par) 6.5 (Ser) | 2.8 (Par) 10.9 (Ser) |
| Xmax (mm) | 12 | 12 | 12 | 12 |
Mounting dimensions (inches)
| Diameter | 10.5" |
|---|---|
| Mounting diameter (cutout) | 9.312" |
| Bolt circle diameter | 10.125" |
| Mounting depth | 5.0" |
Recommended enclosures
- Sealed: minimum 0.65 ft³, optimum 0.75 ft³
- Example closed-box internal dimensions: 7.5" × 11" × 13.75"
The Alumapro difference
Alumapro has built aluminum-cone subwoofers in the USA since 1994. An aluminum alloy cone stays rigid under power where paper and poly cones flex, and it helps draw heat away from the voice coil, so bass stays tight and controlled when you turn it up. Every Alumapro sub is hand built in Huntley, Illinois.
Buy direct from ShopAlumapro.com, the main online home of Alumapro. Every order comes with the 2-year warranty, free shipping on orders of $499 or more, and real support from our team in Cary, Illinois. Questions about your build? Talk to us.
