Zapco HB 810 II 8AD 10-Ch. DSP / 4-Ch. Class-AB + 4-Ch. Class-D Amplifier

Zapco HB 810 II 8AD 10-Ch. DSP / 4-Ch. Class-AB + 4-Ch. Class-D Amplifier

Zapco HB 810 II 8AD – 10-Ch. DSP / 4-Ch. Class-AB + 4-Ch. Class-D Amplifier

ZAPCO presents the Harmony Blue Note Series, a full line of DSP/Amps. All the DSP/Amps share BT streaming and an Integrated Music Player. The full functions GUI offers a complete set of DSP tools, both for PC and Mobile, and has been designed to be intuitive for everyone.

Specifications

Type 10-Ch. DSP / 4-Ch. Class-AB + 4-Ch. bridgeable Class-D
Power, 4Ω 4 x 35 W (AB) + 4 x 100 W (D)
Power, 2Ω 4 x 50 W (AB) + 4 x 150 W (D)
Power, Bridged 4Ω 2 x 300 W (D)
Low level in/out 2 x RCA in, 10 x RCA out
DSP 31-Bands DSP; Crossover / Delay / Phase / EQ
BT streaming Included v 5.2; Integrated Music Player
Frequency response 20 Hz - 20 KHz
Signal stage S/N > 100 dB
Dimensions (mm) 190 x 166 x 45.5
$749.99 USD
