Alumapro Alusonic EX 10 10-Inch Metal Cone Subwoofer
Alumapro Alusonic EX 10 10-Inch Metal Cone Subwoofer
Pre-order — current lead time is 4 weeks. Each Alusonic EX is hand built to order. Order now to reserve yours; it ships as soon as it's built.
The Alusonic EX 10 is the most direct way into Alumapro aluminum-cone bass. Alumapro's proprietary aluminum cone, a laminated Nomex suspension and 10 mm of excursion turn a small sealed box into deep, controlled low end.
Highlights
- Proprietary aluminum cone
- Heat-dissipating integrated cone assembly
- High-temp aluminum composite voice coil
- Vented motor structure
- Laminated Nomex suspension with high-roll Santoprene rubber surround
- Heavy-gauge steel frame, 5.0-inch mounting depth
- 250 W RMS / 400 W peak
- Available in single 4-ohm, single 8-ohm, dual 4-ohm and dual 6-ohm voice coil
Best for
Sealed boxes of 0.65–0.75 ft³. Also available: the Alusonic EX 10 Free-Air.
Specifications
| Parameter | Single 4 Ohm | Single 8 Ohm | Dual 4 Ohm | Dual 6 Ohm |
|---|---|---|---|---|
| Impedance (Ohms) | 4 | 8 | 4/4 DVC | 6/6 DVC |
| Fs (Hz) | 35 | 36 | 36 | 36 |
| Qms | 6 | 6 | 6 | 5 |
| Qes | .55 | .52 | .52 | .5 |
| Qts | .5 | .48 | .48 | .46 |
| Vas (Ft³) | 1.0 | 1.0 | 1.0 | 1.1 |
| Re (Ohms) | 3.9 | 7.9 | 1.8 (Par) 7.1 (Ser) | 2.8 (Par) 10.9 (Ser) |
| Xmax (mm) | 10 | 10 | 10 | 10 |
Mounting dimensions (inches)
| Diameter | 10.125" |
|---|---|
| Mounting diameter (cutout) | 9.187" |
| Bolt circle diameter | 9.75" |
| Mounting depth | 5.0" |
Recommended enclosures
- Sealed: minimum 0.65 ft³, optimum 0.75 ft³
- Example closed-box internal dimensions: 7.5" × 11" × 13.75"
The Alumapro difference
Alumapro has built aluminum-cone subwoofers in the USA since 1994. An aluminum alloy cone stays rigid under power where paper and poly cones flex, and it helps draw heat away from the voice coil, so bass stays tight and controlled when you turn it up. Every Alumapro sub is hand built in Huntley, Illinois.
Buy direct from ShopAlumapro.com, the main online home of Alumapro. Every order comes with the 2-year warranty, free shipping on orders of $499 or more, and real support from our team in Cary, Illinois. Questions about your build? Talk to us.
